This is going to be a sticky topic. I am going to put in important notes parts info that I have collected over the years.    I would also like to get a parts database set up and running.  So if you have recently bought a part for your car.  Please post in this topic.

Part Number, Location you bought it, price you paid for it.  If you have an invoice number to use as a reference, and don't mind posting it, please also add that.  Well here is the first stuff





Capt Fiero
88 Fiero GT 5spd V6
Eight Fifty Seven GT V8 5spd.
Back to Top
Capt Fiero View Drop Down
Admin Group
Admin Group
Avatar
Founding Member

Joined: 12 February 2007
Location: Canada
Status: Offline
Points: 4038
Post Options Post Options   Quote Capt Fiero Quote  Post ReplyReply Direct Link To This Post Posted: 16 February 2007 at 6:14pm
Capt Fiero
88 Fiero GT 5spd V6
Eight Fifty Seven GT V8 5spd.
Back to Top
Capt Fiero View Drop Down
Admin Group
Admin Group
Avatar
Founding Member

Joined: 12 February 2007
Location: Canada
Status: Offline
Points: 4038
Post Options Post Options   Quote Capt Fiero Quote  Post ReplyReply Direct Link To This Post Posted: 16 February 2007 at 6:15pm
Capt Fiero
88 Fiero GT 5spd V6
Eight Fifty Seven GT V8 5spd.
Back to Top
Dr.Fiero View Drop Down
Senior Post God
Senior Post God
Avatar

Joined: 12 February 2007
Location: Canada
Status: Offline
Points: 1726
Post Options Post Options   Quote Dr.Fiero Quote  Post ReplyReply Direct Link To This Post Posted: 17 February 2007 at 8:50am
Well, you've gotta figure I've bought one or two parts over the ages...  ;)


Category Part description Part number Vend. Mfg.
A/C A/C Condensor 3266 Perf.Rad. Perf.Rad.
A/C A/C Heater core 8203 Perf.Rad. Perf.Rad.
A/C Orifice tube A8292 Napa Evercool
A/C R134a conversion kit 940663 Lordco ?
A/C R134a drier (88) - doesnt fit well! 500048 Lordco ?
Body Door hinge pins (2 req'd) 38407 Lordco Help!
Body Door lock cylinders & keys xxxx Napa Napa
Body Trunk lock & keys (notchback) xxxx Napa Napa
Brake Bleeder screw S22660 Lordco Raybestos
Brake Brake Cable - Front BC93267 Lordco Raybestos
Brake Brake Cable - Left BC93902 Lordco Raybestos
Brake Brake Cable - Right BC93903 Lordco Raybestos
Brake Brake Caliper - F or R - L/H - GA C154 Lordco Fenco
Brake Brake Caliper - F or R - R/H - GA C155 Lordco Fenco
Brake Brake Caliper - Front - L/H - 88 only C8091 Lordco Fenco
Brake Brake Caliper - Front - R/H - 88 only C8090 Lordco Fenco
Brake Brake Caliper - Front - rebuild kit - early car WK1076

Brake Brake Caliper - Rear - L/H - early car C275 Lordco Fenco
Brake Brake Caliper - Rear - R/H - early car C274 Lordco Fenco
Brake Brake Caliper - Rear - rebuild kit - early car WK1576 Lordco Raybestos
Brake Brake Hardware - Rear - early car H5592 Lordco Carlson
Brake Brake Hose - L/H - Front - 88 only BH38654 Lordco Raybestos
Brake Brake Hose - L/H - Front - early car BH38350 Lordco Raybestos
Brake Brake Hose - L/H - Rear - 88 only


Brake Brake Hose - L/H - Rear - early car BH38345 Lordco Raybestos
Brake Brake Hose - R/H - Front - 88 only BH28653 Lordco Raybestos
Brake Brake Hose - R/H - Front - early car BH38349 Lordco Raybestos
Brake Brake Hose - R/H - Rear - 88 only


Brake Brake Hose - R/H - Rear - early car BH38346 Lordco Raybestos
Brake Brake Pads - All corners - GA Conv. PGD289M Lordco Raybestos
Brake Brake Pads - Front - 88


Brake Brake Pads - Front - early car PGD261M Lordco Raybestos
Brake Brake Pads - Rear - 88


Brake Brake Pads - Rear - early car PGD262M Lordco Raybestos
Brake Brake Rotor - All corners - GA Conv. 5558 Lordco Lordco
Brake Brake Rotor - Front - early car 5553 Lordco Aimco
Brake Brake Rotor - Rear - early car 5554 Lordco Aimco
Brake Front Rotor Seals - early car 14475 Lordco CR
Brake Master Cylinder 84-87 rebuilt M1988 Lordco Fenco
Brake Master Cyliner rebuild kit (84-87) MK1721
Raybestos
Clutch 13/16" slave cylinder SC37795 Lordco Raybestos
Clutch 15/16" slave cylinder SC37794 Lordco Raybestos
Clutch 2nd design Master cylinder CMA39608 Lordco Raybestos
Clutch 2nd design Master cylinder rebuild kit CMK1956 Lordco Fix -->
Clutch 4spd release bearing N3015 Lordco NSK
Clutch 87-88 slave cylinder 18030137 GM Delco
Clutch Disc & Plate (V6 4spd) NU1888 Lordco Dynapak
Clutch Disc & Plate (V6 5spd) NU31165 Lordco Dynapak
Clutch Disc & Plate (V6 5spd) MS361914 Best Buy Center Force
Clutch Grind Flywheel -none- Lordco Lordco
Clutch Isuzu release bearing N4042 Lordco
Cooling Sys 1 core HD Radiator 828 Perf.Rad. Perf.Rad.
Cooling Sys Could be T-stat to heater core pipe 18853 Napa Gates
Cooling Sys Crossover to L/H main coolant tube 21532 Napa Gates
Cooling Sys Crossover to L/H main coolant tube (88) 21763 Napa Gates
Cooling Sys Heater Core ? Perf.Rad. Perf.Rad.
Cooling Sys Heater core pipes to heater core  28466 Napa Gates
Cooling Sys L/H main coolant tube to radiator 8151 Napa Gates
Cooling Sys Non A/C heater core 8204 Perf.Rad. Perf.Rad.
Cooling Sys R/H main coolant tube to radiator 7665 Napa Gates
Cooling Sys Snakey pipe (r/h side of eng cpt to htr core) 19602 Napa Gates
Cooling Sys Snakey pipe to water pump fitting 8228 Napa Gates
Cooling Sys Thermostat housing to X-over pipe 20661 Napa Gates
Cooling Sys T-stat housing to throttle body heater lines 18020 Napa Gates
Cooling Sys T-stat housing to throttle body heater lines 5/16" * 3" Napa Gates
Cooling Sys Water pump P1221 Lordco Fenco
Cooling Sys Water pump (New) FP1843 Lordco Federal Mogul
Cooling Sys Water pump to R/H main coolant tube 21594 Napa Gates
Cooling Sys Water pump to R/H main coolant tube (88) 21758 Napa Gates
Drive Train Bearing Assy, Rear hub BR930091K Lordco SKF
Drive Train L/H CV Shaft 5542 Lordco Fenco
Drive Train R/H CV Shaft 5563 Lordco Fenco
Drive Train R/H CV Shaft (automatic) 5518 Lordco Fenco
Drive Train Trans. Output seals 13750 Lordco CR
Electrical Alternator (85-87) (w A/C) AL559X Lordco Bosch
Electrical Alternator (85-87) (w A/C) 90013171 Lordco Wilson
Electrical Alternator (88) AL650X Lordco Bosch
Electrical Connector - temp gauge sender 5618C Lordco Pico
Electrical EGR Control valve 214-361 ('86 Auto) Lordco Delco
Electrical Flasher Unit EL12 Lordco Stant
Electrical Getrag B/U light switch D2219A Lordco Delco
Electrical Getrag B/U light switch 10075403 GM GM
Electrical Headlight relay 10031018 GM GM
Electrical
Electrical
Headlight isolation relay
Headlight Switch
NLA
DS294

Standard
Electrical Ignition box 685 Lordco Mallory
Electrical Ignition Cylinder Assy DR141Y Lordco Neihoff
Electrical Ignition Module D1943a Lordco AC Delco
Electrical Junction block (by C500) 3996270 GM GM
Electrical Low-temp rad fan switch TS25691 Lordco Neihoff
Electrical Low-temp rad fan switch FS113 Napa Echlin
Electrical MAP Sensor (1 bar)


Electrical MAP Sensor (2 bar)


Electrical MAT Sensor
Electrical MSD 6A box 6200 Best Buy MSD
Electrical MSD Blaster SS coil 8207 Best Buy MSD
Electrical MSD GM Blaster II coil 8226 Best Buy MSD
Electrical MSD harness adaptor 8876 Best Buy MSD
Electrical Oil pressure Sender (85-87) 10045775 GM GM
Electrical Oil pressure Sender (88)


Electrical Temp sender (gauge) DR138B Lordco Neihoff
Electrical Throttle Position Sensor FE4001 Lordco Neihoff
Exhaust KFG Headers -none- KFG KFG
Exhaust Main flange bolts & springs 03091 Lordco Help!
Exhaust Main flange doughnut gasket 60538 Lordco Felpro
Misc. 2.8L Harmonic Balancer 594-008
Dorman
Misc. EGR tube gasket (w/restrictor) CRB225212 Napa
Misc. Mallory rising rate regulator 4305M Best Buy Mallory
Misc. Saginaw (14mm) to AN -6 Adaptors  991954 Mopac Earls
Misc. Saginaw (16mm) to AN -6 Adaptors  991955 Mopac Earls
Mounts 85-87 V6 engine 2472 Lordco Anchor
Mounts 88 5spd firewall side 2762 Lordco Anchor
Mounts 88 5spd trunk side 2467 Lordco Anchor
Mounts 88 V6 engine 2548 Lordco Anchor
Mounts Poly Cradle mounts 7-502BL Mopac Prothane
Mounts Rear cradle bolts 15677731 GM GM
Rebuild Bottom end gaskets (85-87) CS86991 Lordco Felpro
Rebuild Bottom end gaskets (88) CS9471 Lordco Felpro
Rebuild Cam bearings SH1364S Heads U. Ertel
Rebuild Cam bearings (SBC) 1235m Lordco Federal Mogul
Rebuild Clean lifters -- FieroHut
Rebuild Crank - Grind -- Lordco
Rebuild Crank - Polish -- Lordco
Rebuild Enviro levy on all services -- Lordco
Rebuild Exhaust Gaskets MS93045 Lordco Felpro
Rebuild Exhaust Manifold Bolts MY08030 Mattic
Rebuild Grind valves (ea) -- Lordco
Rebuild Head Bolts ES72857 Lordco Felpro
Rebuild Head Bolts (2 sets req'd) GS33223 Napa Victor
Rebuild Head dowels (2 sets req'd) ES74013 Lordco Felpro
Rebuild Head gasket (individual) 8699PT-2 Lordco Felpro
Rebuild Hot tank block -- Lordco
Rebuild Hot tank head (ea) -- Lordco
Rebuild Intake Gaskets MS93020 Lordco Felpro
Rebuild Lifters HT2095 Lordco Sealed Power
Rebuild Magnaflux block -- Lordco
Rebuild Magnaflux head (ea) -- Lordco
Rebuild Main Bearings 7242MA Lordco Federal Mogul
Rebuild Main Bearings 7242MA Napa Federal Mogul
Rebuild Oil Pump 224-4148 Lordco Sealed Power
Rebuild Oil Pump - High Volume 224-4148V Lordco Federal Mogul
Rebuild Performance Cam C9H Colt
Rebuild Pistons - 2.8 1158P Cdn HiPo Silvolite
Rebuild Pistons - 3.1 H562CP Napa Federal Mogul
Rebuild Push Rods PR342 Napa Ertel
Rebuild Re&Re cam bearings (all) -- FieroHut
Rebuild Rebore (each hole) -- Lordco
Rebuild Reface Lifters -- Colt
Rebuild Rehang pistons/rods (each) -- Lordco
Rebuild Replace valve guide (ea) -- Lordco
Rebuild Resize connecting rod -- Lordco
Rebuild Resurface block -- Lordco
Rebuild Resurface head (ea) -- Lordco
Rebuild Rings - 2.8 2m5632 Cdn HiPo Hastings
Rebuild Rings - 3.1 E605K Napa Federal Mogul
Rebuild Rod Bearings 6-4020A Lordco Federal Mogul
Rebuild Rod Bearings 6-4020A Napa Federal Mogul
Rebuild Roller Rockers (1.52:1) 1413-12 Best Buy Comp-Cams
Rebuild Roller Rockers (1.6:1) 1414-12 Best Buy Comp-Cams
Rebuild Throttle body gasket ? Lordco Felpro
Rebuild Timing chain/gears C3067 Lordco Cloyes
Rebuild Timing chain/gears (true roller) 9-3137 Lordco Cloyes
Rebuild Timing cover gasket set TCS45467 Lordco Felpro
Rebuild Timing cover gasket set w/o speedy sleeve TCS45466 Lordco Felpro
Rebuild Top end gaskets HS8699PT5 Lordco Felpro
Rebuild Valve Cover Gaskets VS50077R Lordco Felpro
Rebuild Valve Springs RV943X Napa Ertel
Suspension Axle seal - Front Inner 14775 Lordco CR
Suspension Axle seal - Rear Inner 18697 Lordco CR
Suspension Ball Joint - Front - Lower K6273 Lordco Moog
Suspension Ball Joint - Front - Lower (88) K5297 Lordco Moog
Suspension Ball Joint - Front - Upper K5292 Lordco Moog
Suspension Ball Joint - Rear - Lower K6257 Lordco Moog
Suspension Bearing - Wheel - Front Inner BR4 Lordco SK/CR
Suspension Bearing - Wheel - Front Outter BR1 Lordco SK/CR
Suspension Bushing - LCA - Front K6163

Suspension Bushing - LCA - Rear ????

Suspension Bushing - UCA - Front K6170

Suspension Lowering springs - 1.5" 60210 Lordco Sus. Tech.
Suspension Lowering springs - 1.5" 3802-140 Lordco Eibach
Suspension Poly - Front control arm 7-207R Lordco Prothane
Suspension Poly - Rear control arm 7-304R Lordco Prothane
Suspension Poly - Sway Bar End-Link 98117R Lordco Energy Susp.
Suspension Rear Camber bolts K5283 Lordco Moog
Suspension Rear Camber bolts (ea) 264-3644 Napa Napa
Suspension Rear Camber bolts (pair) 82110 Lordco Spec. Tools
Suspension Shock Absorber - Front (84-87) 5921 (Sensa-Trac) Lordco Monroe
Suspension Shock Absorber - Front Gas-a-Just (84-87) KG4538 Lordco KYB
Suspension Shock Absorber - Front Gas-a-Just (88) KG4513 Lordco KYB
Suspension Shock Absorber - Front GR-2 (88) 343127

Suspension Strut - Rear (84-88) 234005 Lordco KYB
Suspension Strut - Rear (84-88) 71814 Lordco Monroe
Suspension Strut - Rear (84-88) 234005 Best Buy KYB
Suspension Tie rod - Front - Inner EV121 Lordco Moog
Suspension Tie rod - Front - Outer ES2232RL Lordco Moog
Suspension Tie rod - Front - Outer (88) ES3238RL Lordco Moog
Transmission 84-86 Muncie Select cable CA-8023 Lordco Pioneer
Transmission 84-86 Muncie Shift cable CA-8011 Lordco Pioneer
Transmission 85-88 Isuzu select cable CA-8014 Lordco Pioneer
Transmission 85-88 Isuzu shift cable CA-8013 Lordco Pioneer
Transmission 86-88 Getrag select cable CA-8021 Lordco Pioneer
Transmission 86-88 Getrag shift cable CA-8015 Lordco Pioneer
Tune-up Air Filter CA3902 Lordco Fram
Tune-up Coolant 35244 Lordco
Tune-up Distributor Cap DR78C Lordco Neihoff
Tune-up Distributor O-ring 54214 Lordco Dynaline
Tune-up Distributor Pickup coil D1987 Lordco Delco
Tune-up Distributor Rotor DR59 Lordco Neihoff
Tune-up Drive belt 5050413 Lordco Dayco
Tune-up Drive belt (A/C) 15370 Lordco Dayco
Tune-up Engine Oil 10W30 Lordco Havoline (etc)
Tune-up Fuel Filter G3727 Lordco Fram
Tune-up Oil Filter PF52C Lordco AC Delco
Tune-up Oxygen Sensor 12014 Lordco Bosch
Tune-up Oxygen Sensor 21002 Lordco NGK
Tune-up PCV Valve FV299 Lordco Fram
Tune-up Rad cap 10230 Lordco Stant
Tune-up Spark Plug leads 706F Lordco Delco
Tune-up Spark Plug leads ? Lordco Bosch
Tune-up Spark Plug leads 127655 Lordco Neihoff
Tune-up Spark Plug leads (blue 8mm) 3172 Lordco MSD
Tune-up Spark Plug leads (blue 8mm) TAY74624 Mopac Taylor
Tune-up Spark Plug leads (red 8.5mm super conductor) 31189 Best Buy MSD
Tune-up Spark Plug leads (red 8mm) TY-74224 Cdn HiPo Taylor
Tune-up Spark Plugs 2139 (UR5's) Lordco NGK
Tune-up Thermostat - 180degree 13818 Lordco Stant
Tune-up Thermostat - 195degree 13819 Lordco Stant
Tune-up Thermostat housing cap 10232 Lordco Stant
Tune-up V6 oil filler cap 10154789 GM Delco


Pricing would be meaningless as it would be out of date by many many years now - and I was probably spending $40K/yr to get it anyhow.  :)

Back to Top
Capt Fiero View Drop Down
Admin Group
Admin Group
Avatar
Founding Member

Joined: 12 February 2007
Location: Canada
Status: Offline
Points: 4038
Post Options Post Options   Quote Capt Fiero Quote  Post ReplyReply Direct Link To This Post Posted: 17 February 2007 at 10:52am
Thank You John.
Capt Fiero
88 Fiero GT 5spd V6
Eight Fifty Seven GT V8 5spd.
Back to Top
Capt Fiero View Drop Down
Admin Group
Admin Group
Avatar
Founding Member

Joined: 12 February 2007
Location: Canada
Status: Offline
Points: 4038
Post Options Post Options   Quote Capt Fiero Quote  Post ReplyReply Direct Link To This Post Posted: 07 March 2007 at 1:43pm

Valve Lash Adjustment order



Capt Fiero
88 Fiero GT 5spd V6
Eight Fifty Seven GT V8 5spd.
Back to Top
Capt Fiero View Drop Down
Admin Group
Admin Group
Avatar
Founding Member

Joined: 12 February 2007
Location: Canada
Status: Offline
Points: 4038
Post Options Post Options   Quote Capt Fiero Quote  Post ReplyReply Direct Link To This Post Posted: 26 October 2007 at 12:00pm

Kinda Neat Chart found on the net.



Breakdown by Year

Year Coupes Sport Coupes SE's GT's Formula's Indy's Mera's Total
1984 7,099 62,070 66,121 - - 1,500 - 136,840
1985 5,280 23,823 24,734 22,534 - - - 76,371
1986 9,143 24,866 32,305 17,660 - - - 83,974
1987 23,603 3,135 3,875 15,968 - - 88 46,581
1988 13,910 - - 6,849 5,643 - 159 26,402
TOTAL: 59,035 113,894 127,035 63,011 5,643 1,500 247 370,168

Breakdown by Color

Year Bright Red Black White Silver Maroon Gold Blue Yellow
1984 65,684 27,368 34,211 9,579 - - - -
1985 24,439 20,620 12,983 18,329 - - - -
1986 28,563 21,216 5,228 12,637 - 16,325 - -
1987 2 !!! 8,402 2,611 6,671 20,264 4,119 4,458 -
1988 10,238 4,602 6,404 1,256 2,729 - - 1,166

Breakdown by Options

Option 1984 1985 1986 1987 1988
Engine: Iron Duke 4 100 % 55.0 % 45.3 % 60.5 % 54.3 %
Engine: High-RPM V6 0.0 45.0 54.7 39.5 45.7
Transmission: 4-Speed 56.7 21.8 21.3 0.0 0.0
Transmission: 5-Speed 0.0 31.2 28.6 45.4 52.4
Transmission: Auto 43.3 47.0 50.1 54.6 47.6
Wheels: Alloy 78.0 85.0 69.8 62.1 99.9
Air Conditioning 79.3 82.7 89.3 93.2 89.3
Power Windows (STD on GT) 45.3 62.5 42.0 7.0 13.3
Power Door Locks 30.4 41.6 43.3 36.9 33.2
Tilt Column 87.6 96.2 74.7 60.5 70.6
Cruise Control 40.3 53.2 52.4 40.6 49.6
Sunroof 50.2 61.3 61.4 35.8 36.6
AM/FM Stereo: Radio 31.8 32.3 22.8 36.8 15.5
AM/FM Stereo: Cassette 42.6 42.6 46.8 44.0 68.3
AM/FM Stereo: Cass w/EQ 0.0 23.4 28.0 16.7 15.4

1988 Breakdowns: Color and Body

Body Style Bright Red White Black Maroon Silver Yellow
Coupe 5,665 3,576 2,072 1,368 738 489
Formula 1,966 1,303 1,106 567 261 436
GT 2,607 1,525 1,424 794 257 241

Capt Fiero
88 Fiero GT 5spd V6
Eight Fifty Seven GT V8 5spd.
Back to Top
Romeo View Drop Down
Senior Post God
Senior Post God
Avatar

Joined: 16 November 2008
Location: Canada
Status: Offline
Points: 3033
Post Options Post Options   Quote Romeo Quote  Post ReplyReply Direct Link To This Post Posted: 18 November 2008 at 2:45pm
In the "Body" Catagory, where it says trunk lock and keys, does that mean one would then have THREE sets of keys (Doors, Ignition and Trunk)? My trunk will barely open unless done so with the eletric switch on the inside (Which is a pain if the battery needs a jumpstart. Need electricity to get to the battery, and need the battery to get electricity. See the paradox?) but I don't want to tote around three keys for my car, that's a touch excessive...
Never shift into reverse without a back-up plan.
Back to Top
Kyng_72 View Drop Down
Member
Member
Avatar

Joined: 30 November 2008
Location: Canada
Status: Offline
Points: 49
Post Options Post Options   Quote Kyng_72 Quote  Post ReplyReply Direct Link To This Post Posted: 13 December 2008 at 8:39pm
Romeo I have heard of remote battery terminals where you can leave your battery in it's stock location and place the remote terminals in a more convenient location like under the front hood.
as the average human male life span is around 72 and I am now 36 can I officially consider my fiero as my midlife crisis car?
Back to Top
Capt Fiero View Drop Down
Admin Group
Admin Group
Avatar
Founding Member

Joined: 12 February 2007
Location: Canada
Status: Offline
Points: 4038
Post Options Post Options   Quote Capt Fiero Quote  Post ReplyReply Direct Link To This Post Posted: 13 December 2008 at 9:17pm
Na easiest way around it is, buy a cheap cig lighter adapter with a pigtail on it, feed 12v through the cig lighter it will power the trunk popper switch.
Capt Fiero
88 Fiero GT 5spd V6
Eight Fifty Seven GT V8 5spd.
Back to Top
Capt Fiero View Drop Down
Admin Group
Admin Group
Avatar
Founding Member

Joined: 12 February 2007
Location: Canada
Status: Offline
Points: 4038
Post Options Post Options   Quote Capt Fiero Quote  Post ReplyReply Direct Link To This Post Posted: 08 January 2010 at 9:41pm
quote
Originally posted by Synthesis:

The 1985/86 Toyota MR2 features a slave cylinder with the same bore size as the steel Isuzu slave cylinder.
The MR2 uses a dual seal piston, vs the single seal on the Fiero.
The part number for the MR2 piston is CHK351359.
The photo below shows the MR2 Piston, boot and spring. To complete this upgrade, you use just the MR2 piston, with the Fiero Isuzu spring.




85 or 86
Capt Fiero
88 Fiero GT 5spd V6
Eight Fifty Seven GT V8 5spd.
Back to Top
Dr.Fiero View Drop Down
Senior Post God
Senior Post God
Avatar

Joined: 12 February 2007
Location: Canada
Status: Offline
Points: 1726
Post Options Post Options   Quote Dr.Fiero Quote  Post ReplyReply Direct Link To This Post Posted: 08 January 2010 at 9:59pm
Originally posted by Capt Fiero Capt Fiero wrote:



The 1985/86 Toyota MR2 features a slave cylinder with the same bore size as the steel Isuzu slave cylinder.


Here's what it looks like...


I made a stock slave cylinder bracket for JohnJohn once... I'm thinking it wouldn't be hard at all to make one to fit this.
Just gotta figure out the thread size for the hydraulics and make an adaptor as required.

It's CHEAP too!  About $45 from NAPA.

(oh, and the reason I say to use the above whole thing vs. just the piston, is then MAYBE we'll get around the CRAP quality castings we've had to contend with...  rust, etc...)


Back to Top
Capt Fiero View Drop Down
Admin Group
Admin Group
Avatar
Founding Member

Joined: 12 February 2007
Location: Canada
Status: Offline
Points: 4038
Post Options Post Options   Quote Capt Fiero Quote  Post ReplyReply Direct Link To This Post Posted: 08 January 2010 at 11:24pm

I don't think the piston travles far enoug in the MR2 bore to work for Maybe in the Getrag but not in the Isuzu.



Great idea though.  THe 84 Slave does mount similar to that MR2 one, maybe look at the 84 Slave and see what you can come up with.

Capt Fiero
88 Fiero GT 5spd V6
Eight Fifty Seven GT V8 5spd.
Back to Top
Dr.Fiero View Drop Down
Senior Post God
Senior Post God
Avatar

Joined: 12 February 2007
Location: Canada
Status: Offline
Points: 1726
Post Options Post Options   Quote Dr.Fiero Quote  Post ReplyReply Direct Link To This Post Posted: 13 January 2010 at 2:23pm
Went and actually fondled the above slave the other day (that sounds just... like..  SO wrong, on so many levels!).

Total travel from me ramming the piston in as deep as it'll go with my thumb, out to the point where the piston was going to pop out (there's NO snap ring retainer!) was about 1-1/8".  So, probably not enough to keep an Isuzu happy.

Too bad.  Looked like good quality metal in comparison to the sh*t castings that we've been getting.

I might still do one up for my Getrag though, as it looks like my slave here is rusted in place (BIG surprise eh?!) and will need replacing.

Back to Top
Bassman View Drop Down
Senior Post God
Senior Post God
Avatar
Sir Brian

Joined: 12 February 2007
Location: Canada
Status: Offline
Points: 2501
Post Options Post Options   Quote Bassman Quote  Post ReplyReply Direct Link To This Post Posted: 05 July 2010 at 6:40pm

AC Delco Oil Filter update at Lordco: What was PF52C, is now PF52F

Harmonic Balancer: Fiero Store or Damper Doctor, 4-8 week back order at Lordco and NAPA could not find the listing

Cheers

Brian (Bassman)
86 GT Fastback 3.2L
2013 Mazda3 Sport GS SkyActive
Back to Top
Dr.Fiero View Drop Down
Senior Post God
Senior Post God
Avatar

Joined: 12 February 2007
Location: Canada
Status: Offline
Points: 1726
Post Options Post Options   Quote Dr.Fiero Quote  Post ReplyReply Direct Link To This Post Posted: 18 July 2012 at 8:29pm
Loose your bushing for the oil pressure sender?

The one for the A/C car is not the same size it would seem.

But I found a Weatherhead 7912, drilled out down the middle will work. There's a tiny tit sticking up that makes it not a great fit, hence drilling it out.  Doesn't take much.  You could even just use a countersink to get rid of it.

Makes sure to use good yellow 'gas tape' (vs white teflon) on both sets of male threads.

Back to Top
 Post Reply Post Reply
  Share Topic

Forum Jump Forum Permissions View Drop Down

Forum Software by Web Wiz Forums® version 11.04
Copyright ©2001-2015 Web Wiz Ltd.
